MAIN FEATURES

• The function of marking software is powerful. The machine can be compatible with software files such as Coredraw, AutoCAD. Compatible with Lighburn.
• The machine can directly use SHX, TTF fonts. Automatic encoding, printing serial number,batch number, date, barcode, QR code, automatic jump number, etc supported.
• Applicable Material: Aluminum, Stainless Steel, Brass, Copper,etc. Also some of nonmetal such as nylon, lightbutton, ABS, PVC, PES,etc.
• Applicable Industry: Hardware industry, wrenches, measuring tools, sanitary ware, stainless steel, medical equipment, luggage, gifts, table bottom, glasses frames, instruments.

TECHINICAL PARAMETERS

• Input Voltage:110V-240V/50-60Hz
• Repetition Rate Frequency: 1-600kHZ@JPT LP-E Pulse Duration: 200ns
• Power Consumption:1000W
• Laser Wavelength: 1064nm
• Software: EZCAD2
• Control board:BJ JCZ board(Original)
• Marking Speed: ≤7000mm/s(275.6in/s)
• Engraving Depth: ≤1mm(0.039in)
• Maximum Material Thickness: 250mm(9.8in)
• Compatible with Windows XP/Vista/7/8/10
• Re-position precision is 0.002mm
• High-Rate of Electrical-Optical Conversion: up to 70%

CARING WARRANTY

1 Year Warranty for the Whole Machine, 2 Years for Laser Source. No import duty and other tax for US Customers. English operation interface. Parameters are intuitive and adjustable. Lifetime technical assistance. Delivered to your door directly by FedEx/DHL/UPS. Of course, if you want to reduce transportation costs(by sea), pls feel free to PM us.

DELIVERY

• Remote Assistance for operation issues
• Lifetime Online Technical Support
• Free Shipping to Your Door by Air (DHL/UPS/Fedex) about 7-15 Days
• No Import Duty for American Customers.
