MAIN FEATURES

• Germany Local Stock & EU Fast Delivery: Ships from our German warehouse to Germany and neighboring EU countries (AT, BE, NL, LU, PL, CZ, DK, FR, etc.) at a **clearance special price**. No long sea freight, no customs surprises. **Local after-sales support provided by Germany-based Mr. Zhou**, with responsive technical help and spare-parts service in your time zone.
• 150W YONGLI Tube + Premium Optics: Equipped with a 150W YONGLI CO2 laser tube (circulating water-cooled), USA II-VI focusing lens, and Singapore-imported reflective lenses for a sharp, stable beam and clean, corrugation-free cuts.
• Ruida 6445G Controller & High Precision: Latest-generation Ruida DSP system (supports BMP / PLT / DST / AI / DXF), stepper motor with subdivision driver, ±0.01mm repetition accuracy, 0.025mm mechanical resolution, and up to 1200mm/s engraving speed across a large 1300×900mm bed.
• Smart Automation & Full Safety Suite: Auto focus, auto blowing with dual smoke outlets, red-dot pointer, electric lifting workbench with honeycomb + slat tables, pass-through door for long materials, and complete protections (open-cover stop, water/light-path/door-lock safety, grounded, rounded sheet-metal edges). S&A ±0.3°C precision chiller included.
• Wide Non-Metal Material Compatibility: Cuts and engraves wood, bamboo, acrylic, double-color sheets, paper, leather, shells, ox horn, resin, ABS, lamp shades, fabric, felt, rubber, glass engraving, and more — ideal for signage, gifts, leathercraft, model making, packaging, and small-batch production.

Configuration:

• SFX-1390 (230V, German version); Yongli H6 or A6S tube; coaxial red dot pointer; CE-certified CO2 laser safety glass; EU-standard power socket; integrated LED lighting strip; light-leakage prevention design.

Standard Features:

• Motorized lifting platform, honeycomb bed, red dot pointer, autofocus, lid-open safety interlock, optical path protection, warning light, and reserved interface for a rotary attachment.

TECHNICAL PARAMETERS

• Item: SFX-1390
• Max. Engraving Area: 1300x900mm
• Engraving Speed: 0-1200mm/sec
• Cutting Speed: 0-300mm/sec
• Laser Power Output Range: 0-100% Adjustable
• Cooling Mode: Water Cooling
• Mechanical Resolution: 0.025mm
• Min. Character: Chinese 2mm, English 1mm
• Repetition Precision: ±0.01mm
• Input Voltage: AC230V/50Hz
• Supported Formats: BMP PLT DST AI DXF
• Driver: Stepper Motor、Subdivision Driver
• Laser Power: YONGLI 150W
• Working Temperature: 0°C~45°C
• Working Humidity: 5%~95%

🚚 Shipping & After-Sales

• 📍 Warehouse Location: Germany (local EU stock)
• 🚢 Shipping To: Germany & neighboring EU countries (AT, BE, NL, LU, PL, CZ, DK, FR, etc.)
• ⏱️ Delivery Time: Fast local EU delivery — no long sea freight
• 🛠️ After-Sales Support: Local support provided by Mr. Zhou (Germany-based) — responsive English/Chinese communication, spare parts, and technical guidance
